Ride-on electric Sweeping machine V2

Short Description:

Ride-on electric sweeper, More sleek and compact form factor and more intelligent design, High quality, high efficiency and high safety, At the same time, it has greater applicability to the use site, It reflects the high design and manufacturing level of domestic pure electric sweepers! (This product has applied for 6 national patents).

Send email to us

Product Detail

Technical Specifications

Efficiency	6800m²/h	Sweep width	1400mm
Main brush length	700mm	Climbing ability	<35⁰
Continuous working hours	4-6h	Power source	36V(3个12V 120ah
Water tank capacity	18L	Trash capacity	150L( The largest of the same car ）
Drive motor	2000W	Side brush diameter	500mm
Turning radius	Turn in place	Operating power (motor) main brush + side brush + fan	700+250+80
Maximum working speed	0—6km/h	Size	1550×1400×1800mm
Filter area	8m²	MAX Speed	0—8km/h
Number of side brushes	two	Total mass	600kg
Ground clearance	80mm	Ceiling	Optional

Products Features

1、Using 2000W AC motor drive combination, the work performance is stable and excellent

2、The body is perfectly welded with No. 45 international standard steel, and the structure is solid Durable. It adopts the anti-rust treatment process of the sedan-grade chassis, which is not easy to rust, paint peeling; Eco-friendly plastic shell adopts ABS engineering plastic material, multi-layer car Paint surface spraying treatment, environmental protection without deformation, strong and durable anti-aging.

3、The patented front wheel suspension design effectively protects the vehicle control system Power system and power system, better protection of the machine is not easy damage, increase operating comfort and overall vehicle safety.

4、Patented secondary dust control system, with vacuum dust system, stronger dust control ability, no secondary dust.
